Brazos FUTABA de Aluminio para Servo para direccion.

Material: Aluminio
Color: Azul

Marcas compatibles:

Brazos FUTABA de Aluminio para Servo para direccion.

Material: Aluminio
Color: Rosa

Marcas compatibles:

Brazos FUTABA de Aluminio para Servo para direccion.

Material: Aluminio
Color: Rojo

Marcas compatibles:

Brazos FUTABA de Aluminio para Servo para direccion.

Material: Aluminio
Color: Titanio

Marcas compatibles:

Specifications:
- Full Aluminum Case (upper, middle, bottom)
- Full Metal Gear V2
- Output Shaft: 25T
- Dynamic Torque: 6.0v 21.1 kg.cm - 7.4v 26.1 kg.cm
- Operating Speed: 6.0v 0.10sec - 7.4v 0.08sec
- Operating Voltage: 6.0v - 7.4v
- Operating Temperature Range : -10 to +60°C
- Motor Type: Ultra efficient brushless motor
- Size: 39.5 x 20.0 x 38.7 mm
- Weight: 73,2 g

- Full Aluminium Case
- Full Metal Gears-POWER GEAR
- Output Shaft: 25T
- Dynamic Torque  (6.0V): 24.5 kg-cm / (7.4V) : 31.1 kg-cm
- Operating Speed (6.0V): 0.12 sec/60° / (7.4V) : 0.09 sec/60°
- Operating Temperature: 14° to 140° F (-10 to +60° C)
- Operating Voltage: 6.0V - 7.4V
- Size: 39.5 x 20.0 x 38.7 mm
- Weight: 73.1g

Specifications:
- Full Metal gears
- Full Aluminium Case
- Dual Ball Bearing
- Coreless motor
- Output Shaft: 25T
- Dynamic torque: 28.3Kg.cm - 36.2Kg.cm
- Speed: 0.13sec/60° - 0.10sec/60°
- Operating Voltage: 6.0V - 7.4V
- Size: 39.6 x 20.0 x 38.9 mm
- Weight: 71.7g

You are looking for some powerful control
We developped these servos with the racer in mind, ultimate digital power, precision and reliable.
Check out these awesome features

Features:
- Full CNC machined alloy case
- High Voltage 6.0 - 8.4V
- Titanium gears
- Ball Raced
- Coreless motor
- Ultra high speed and torque
- Water resistant

You are looking for some powerful control
We developped these servos with the racer in mind, ultimate digital power, precision and reliable.
Check out these awesome features

Features:
- Full CNC machined alloy case
- High Voltage 6.0 - 8.4V
- Titanium gears
- Ball Raced
- Coreless motor
- Ultra high speed and torque
- Water resistant

Specifications:
- Full Metal gears
- Full Aluminium Case
- Dual Ball Bearing
- Coreless motor
- Output Shaft: 25T
- Dynamic torque: 31.4Kg.cm - 40.2Kg.cm
- Speed: 0.12sec/60° - 0.09sec/60°
- Operating Voltage: 6.0V - 7.4V
- Size: 39.6 x 20.0 x 38.9 mm
- Weight: 71.7g

Specifications:
- High Efficiency Coreless Motor
- Full Aluminium Case
- Full Metal(Steel) Gears
- Output Shaft 25T
- Dynamic Torque  6.0v 12.4 kg-cm  -  7.4v: 15.1 kg-cm
- Operating Speed 6.0v 0.11 sec/60° - 7.4v: 0.08 sec/60°
- Operating Temperature 14° to 140° F (-10 to +60° C)
- Operating Voltage 6.0V~7.4V
- Size 39.5 x 20.0 x 38.7 mm

Specifications:
- 32Bit MCU
- High Efficiency Coreless Motor
- Full Aluminium Case + Plastic Bottom Case
- Full Metal Gears
- Output Shaft 25T
- Operating Speed (6.0V): 0.07 sec/60° (7.4V): 0.06 sec/60°
- Dynamic Torque (6.0V): 7.1 kg-cm (7.4V): 8.3 kg-cm
- Operating Temperature: 14° to 140° F (-10 to +60° C)
- Operating Voltage: 6.0v - 7.4v
- Size: 39.5 x 20.0 x 30.3 mm
- Weight: 54.5g

Precio: 39.90E, Nueva gama de servos con piñonería de titanio. Eficaces y precisos gracias a los nuevos motores coreless. Velocidad: 0.08 seg, Fuerza: 9.3 kgs-cm, Peso: 45g, Rodamientos: Dual, Piñonería: Titanio y Aluminio, Piñón: 25T, Tamaño (Largo - Anc

Specifications:
- Full Metal gears
- Full Aluminium Case
- Dual Ball Bearing
- Coreless motor
- Output Shaft: 25T
- Dynamic torque: 14.2Kg.cm - 16.8Kg.cm
- Speed: 0.12sec/60° - 0.09sec/60°
- Operating Voltage: 6.0V - 7.4V
- Size: 39.5 x 20.2 x 38.7 mm
- Weight: 70.4g

Specifications:
- Full Aluminium Case
- Full Metal gears
- Dual Ball Bearing
- Ultra efficient Coreless motor
- Output Shaft: 25T
- Dynamic torque: 17.8Kg.cm - 21.7Kg.cm
- Operating Voltage: 6.0V - 7.4V
- Speed: 0.09sec/60° - 0.07sec/60°
- Size: 39.5 x 20.0 x 38.7 mm
- Weight: 70.4g

Specifications:
- Full Metal gears
- Aluminum Middle Heatsink
- Dual Ball Bearing
- High efficient cored DC motor
- Operating Voltage: 6.0V - 7.4v
- Dynamic torque: 7.2Kg.cm - 7.9Kg.cm
- Speed: 0.13sec/60° -  0.11sec/60°
- Size: 39.5 x 20.0 x 38.6 mm
- Weight: 54.9g

Specifications:
- Full Metal gears
- Aluminum Middle Heatsink
- Dual Ball Bearing
- Output Shaft: 25T
- Dynamic torque: 13.8Kg.cm - 16.2Kg.cm
- Speed: 0.12sec/60° - 0.09sec/60°
- Coreless motor
- Operating Voltage: 6.0V - 7.4V
- Size: 39.5 x 20.0 x 38.6 mm
- Weight: 61.6g

Precio: 1.90E, Brazos de plastico de Servo para direccion. Compatible con diferentes marcas de Servo: Futaba, ACE, Savox, Orion, Siim, Tower Pro, Ace/Thunder Tiger, Blue Bird, Cirrus, Duratrax, HPI, Hobbico, Tamiya, Traxxas...

Precio: 14.90E - Fuerza: 12-15 kgs*cm Medidas: 40.8 mm. x 19.9 mm. x 37.3 mm. Temperatura de uso: - 20 a 60 ºC. Voltaje de trabajo: 4.8 V ~ 7.2 V. Tipo de rodamientos: Rodamientos de doble bola. Tipo de piñones: todo en metal. Longitud cable: 150 mm. Incl

Precio: 25.00E - OFERTA: Servo HI-Speed MG995 Digital 15kgs x2 uds. Equipa tu coche rc con el mejor servo relación calidad / precio.

Precio: 14.90E, - Medidas: 40.7 mm. x 19.7 mm. x 42.9 mm. - Potencia: 10Kg - Voltaje de trabajo: 4.8 V ~ 7.2 V. - Velocidad de operación: 0.20sec/60 grados (4.8v) - Tipo de rodamientos: Rodamientos de doble bola. - Tipo de piñones: todo en metal. - Longit

Features:
Digital Servo
Voltage: 6.0 - 8.4v
Dual Ball Bearing - Ministry of Bearing
Brushless Motor
Gears Material: Titanium and Alloy
Speed 6.0v: 0.100 sec/60
Speed 7.4v: 0.083 sec/60
Speed 8.4v: 0.071 sec/60
Torque 6.0v: 18.0kg.cm
Torque 7.4v: 23.0kg.cm
Torque 8.4v: 25.0kg.cm
Size: 40x20x37.2 mm
Weight: 79.0g

Aluminium Metal Case

Features:
Digital Servo
Voltage: 6.0 - 8.4v
Dual Ball Bearing - Ministry of Bearing
Brushless Motor
Gears Material: Titanium and Alloy
Speed 6.0v: 0.085 sec/60
Speed 7.4v: 0.070 sec/60
Speed 8.4v: 0.055 sec/60
Torque 6.0v: 13.0kg.cm
Torque 7.4v: 15.0kg.cm
Torque 8.4v: 18.0kg.cm
Size: 40x20x37.2 mm
Weight: 79.0g

Aluminium Metal Case

Features:
Digital Servo
Voltage: 6.0 - 8.4v
Dual Ball Bearing - Ministry of Bearing
Brushless Motor
Gears Material: Titanium and Alloy
Speed 6.0v: 0.074 sec/60
Speed 7.4v: 0.067 sec/60
Speed 8.4v: 0.058 sec/60
Torque 6.0v: 10.0kg.cm
Torque 7.4v: 12.0kg.cm
Torque 8.4v: 13.5kg.cm
Size: 40.8x20.2x26.1 mm
Weight: 62.0g

Aluminium Metal Case

Features:
- Waterproof IP67
- Voltage: 6.0 - 8.4v
- Working frec: 1520 Us 333Hz
- Dual ball bearings - Ministry of Bearing
- Motor: Coreless
- Gears: Titanium and Alloy
- Speed 6.0v: 0.160 sec/60
- Speed 7.4v: 0.145 sec/60
- Speed 8.4v: 0.135 sec/60
- Torque 6.0v: 26.0kg.cm
- Torque 7.4v: 29.0kg.cm
- Torque 8.4v: 32.0kg.cm
- Size: 40x20x37.2 mm
- Weight: 73.5g

Aluminium Metal Case

Features:
- Servo Digital
- Waterproof IP67
- Voltage: 6.0 - 8.4v
- Working frec: 1520 Us 333Hz
- Dual ball bearings Ministry of Bearing
- Motor: Brushles
- Gears: Titanium and Alloy
- Speed 6.0v: 0.115 sec/60
- Speed 7.4v: 0.100 sec/60
- Speed 8.4v: 0.085 sec/60
- Torque 6.0v: 34.0kg.cm
- Torque 7.4v: 39.0kg.cm
- Torque 8.4v: 45.0kg.cm
- Size: 40x20x37.2 mm
- Weight: 84.0g

Aluminium Metal Case

Features:
- Servo Digital
- Voltage: 4.8 - 6.0v
- Working frec: 1520 Us 333Hz
- Dual Ball bearing Ministry of Bearing
- Motor: Brushed
- Gears: Metal
- Torque 4.8v: 16.0kg.cm
- Torque 6.0v: 18.0kg.cm
- Size: 40x20x40 mm
- Weight: 55.0g

Precio: 34.90E, Servo SAVOX SC-0252MG Digital 10.5 Kgs - Coreless. Velocidad: 0.13 seg, Fuerza: 10.5 kg-cm, Peso: 49g, Rodamientos: Dual, Piñonería: Acero, Piñón: 25T, Tamaño (Largo - Ancho - Alto): 40.8 x 20.2 x 37.4 mm, Caja de plastico

Precio: 9.90E - Fuerza: 3 kgs*cm - Dimensiones: 39.5x20.0x39.5mm - Peso: 49.0 gr

Precio: 11.90E - Fuerza: 9 kgs x cm - Dimensiones: 39.5x20.0x39.5mm - Peso: 49.0 gr

KEY FEATURES
- Ideal for 1/10 on road applications
- incredible efficiency and low power consumption
- Aluminium case for good heat dissipation
- NMB dual main bearings
- 25T output shaft

Application :
1/10 On-road, 1/10 Off-road, 1/8 On-road, 1/8 Off-road

Specifications:
- Type: Digital
- Bearing: Dual
- Motor Type: Brushless
- Gear Material: Titanium & Alu.
- Control system: pulse width control
- Voltage: 6.0 - 8.4v
- Temp. range: -10 to + 60 degree
- Speed (6.0v): 0.062 sec/60 deg
- Speed (7.4v): 0.052 sec/60 deg
- Speed (8.4v): 0.045 sec/60 deg
- Torque (6.0v): 10kg.cm
- Torque (7.4v): 13kg.cm
- Torque (8.4v): 15kg.cm
- Potentiometer drive: direct drive
- Dimensions: 41.0x20.0x26.4 mm
- Weight: 43gr.
- Connector wire length: jr 180 mm

KEY FEATURES
- Unique Mechanic Design
- incredible efficiency and low power consumption
-  Standard dimension make it perfect for vehicles that can benefit from a high quality servo
-  CNC Machined aluminium case for exceptional cooling
-  HD 4096 Resolution
-  2 μsec Dead Band
-  Superior Holding Torque

Application:
1/10 Off-road  1/10  On-road

Main features:
- Unique Mechanic Design
- Incredible efficiency and low power consumption
- Standard dimension make it perfect for vehicles that can benefit from a high quality servo
- CNC Machined aluminum case for exceptional cooling
- SSR mode compatible
- 2 μsec Dead Band
- Superior Holding Torque
- 1-Year Limited Warranty

Application:
1/10 On-road & 1/8 On-road

Application:
1/10 on road and 1/8 off road & Helicopter

SRT SERVO OVERVIEW
The latest generation of SRT  servos provides you with the performance you need for any scale vehicle Air PlaneBoatRobot application. are standard size servos for High-Voltage applications up to 8.4V, feature all metal case construction for the ultimate performance.

KEY FEATURES
- Ideal for 1/8 on road and 1/8 off road scale applications
- Superior Holding Torque
- incredible efficiency and low power consumption
- Standard dimension make it perfect for rc vehicles
- CNC Machined aluminium case for exceptional cooling
- NMB dual main bearings
- 25T output shaft
- HD 4096 Resolution
- 2 μsec Dead Band

Application:
1/8 on road and 1/8 off road
